18 Operations Guidance pattern use
Swaths Management screen
From the Mapping Guidance panel, you can access the Swaths Management screen by tapping
. The tabs on this screen are:
Tab On this tab, you can: See...
Swaths
Choose the type of pattern you
want to create
Straight guidance pattern (page
361)
Curved pattern (page 363)
Headland pattern (page 364)
Pivot pattern (page 367)
Shift, rename or export an
existing pattern
Rename a swath (page 376)
Shift a swath (page 378)
Import or delete an existing
pattern
Import AB Lines or boundaries
(page 373)
Delete a swath (page 377)
Add an access path
Access paths (page 372)
Line Features A list of line features you have
created and can load.
Field feature use (page 356)
FreeForm
Set when the path is recorded
and whether you want the U-
turn at the end of a path to be
recorded.
Delete all line segments created
in your FreeForm pattern.
FreeForm pattern (page 369)
Features A list of features you have
created in the field.
Field feature use (page 356)
The buttons on the bottom of the Swaths Management screen are:
Buttons Tap to... See...
No AB Prevents the ABguidance lines from
being loaded (for WM Form
activities).
New FreeForm Begin a new FreeForm line and go to
the Run screen.
FreeForm pattern (page
369)
Version 9.25, Revision B FM-1000 Integrated Display User Guide 359
