Trimble FM-1000 - Mapping location setting

6 Field feature mapping setup Mapping location setting
Mapping location setting
As you place features in your on-screen field, they are placed in relation to the:
l Center of the boom
l Right of the boom
l Left of the boom
Access these settings at the Feature Mapping screen.
1.
At the Home screen tap . The Configuration screen displays.
2.
Select System and tap Setup. The Display Setup screen displays.
3. Select Feature Mapping and tap Setup. The Feature Mapping screen displays.
4.
Complete the settings for the Mapping Location section and tap OK.
Setting Explanation
Point Features
Point features should be placed in your on-screen field
relation to:
ll Boom Center:The center of the boom
l Boom Right:To the right of the boom
l Boom Left:To the left of the boom
Line / Area Features
Line and area features should be placed in your on-screen
field relation to:
ll Boom Center:The center of the boom
l Boom Right:To the right of the boom
l Boom Left:To the left of the boom
Version 9.25, Revision B FM-1000 Integrated Display User Guide 145
