19 Diagnostics System diagnostics
CAN Bus data
You can view CANBus data as the display receives it.
To view the data:
1.
At the Configuration screen, select System and then tap Diagnostics.
2. Go to the CANBus tab.
3. To view the data from a port, tap View. The port diagnostics screen for that port displays.
4. To capture data, tap the Capture button. Approximately five seconds of serial data is captured
and then displays on the screen. You can review the data or capture another snapshot of data.
5. To close the screen, tap OK.
Configuration data
1.
To view display configuration information, tap .
2.
The Home screen shows:
ll Display firmware information
l Autopilot controller information
l GPS receiver and correction method information
l Vehicle make and model
Network diagnostics
1.
At the Configuration screen, tap System and then tap Diagnostics.
2.
Go to the Network tab.
The status of various network connections display.
To enable Remote Assistant, select Enabled.
