13 TrueGuide setup TrueGuide setup
TrueGuide setup
1.
At the Configuration screen, select TrueGuide and then tap Setup. The TrueGuide Setup
screen displays.
2.
Enter the required settings.
Setting Explanation
Roll compensation
ll On: Applies roll corrections from the tractor.
l Off: Applies no roll corrections.
CurveGuide
ll Off: The system does not anticipate curves.
l TrueGuide only: Enables the system to anticipate
curves to make corrections for TrueGuide guidance
only.
l Always On: Keeps CurveGuide on at all times.
TrueGuide Aggressiveness The default aggressiveness. The recommended
aggressiveness is 100%. See System aggressiveness settings.
3. Tap OK. The Configuration screen displays.
System aggressiveness settings
Aggressiveness affects the response of the implement to move to the guidance line. When
aggressiveness is:
l Increased:The response to move the implement back to the guidance line is increased.
l Decreased:The response to the implement moving offline is smoothed.
1.
At the Run screen, tap to open the TrueGuide panel.
2.
Use + or - to increase or decrease the aggressiveness.
For... Use the default setting...
Steep slopes (10% - +30%) 150%
Slow speed operations 125%
Normal operation 100%
High speed applications (> 8 mph or 12.8 kilometers per hour) 33%
Version 9.25, Revision B FM-1000 Integrated Display User Guide 271
