18 Operations TrueTracker operation
TrueTracker operation
WARNING – Many large and sudden changes in satellite geometry caused by blocked satellites can cause
significant position shifts. If operating under these conditions, auto-guidance systems can react abruptly. To avoid
possible personal injury or damage to property under these conditions, disable the auto-guidance system and take
manual control of the vehicle until conditions have cleared.
When using TrueTracker with the Autopilot system, the implement receives its own separate
guidance and steering to increase accuracy.
TrueTracker controls
To open the TrueTracker panel, tap .
Control Explanation
Nudge
The guidance line can move off target due to either:
l GPSposition drift after pausing or turning off the system
l GPSsatellite constellation changes as you drive in the field
Use the < and > buttons to move the guidance line in a perpendicular
direction (left or right).
Aggr Use the - and + buttons to adjust how aggressively the implement
moves to the guidance line.
Zero Steering
Off: Zero Steering is not used.
On: Commands the steering to zero degrees left/right, centering the
steering device on the implement. This option can be turned on in the
field, keeping the coulters pointed straight, or just at the ends of the
field to center the steering.
Note –
Disengaging the TrueTracker system automatically turns off Zero
Steering.
Engage button
How the Engage button works depends on how the TrueTracker system has been set up.
Note – For settings on Engage, see Engage settings for TrueTracker system (page 279).
Version 9.25, Revision B FM-1000 Integrated Display User Guide 423
