9 Field-IQ system setup Equipment calibration for Field-IQ
4. When the auto tuning is finished, tap Next.
5.
On the Drive Settings tab, turn the master switch on and vary the rates. Then adjust the values on
this tab, if necessary.
6. Tap Next. On the Info tab, the results and drive limits of the calibration are listed. This screen is
used to show the applicators operating range. If the speeds that are displayed are not logical,
there is a setting issue. You may also need to perform a catch test for these numbers to be
accurate.
Flow Calibration
WARNING – During flow calibration, the machine will become operational. Take all necessary precautions to
ensure user safety. Failure to do so may result in serious injury or death.
Flow calibration is used to check the accuracy of the:
l Gear ratio (if applicable)
l Gate settings (if applicable)
l App rate sensor
WARNING – Moving parts during this operation. Ensure the implement is safe to operate.
This is done by performing a catch test.
1. At the Field-IQ Calibration screen, select Flow Calibration under the valve you want to caibrate.
The Planter Calibration screen displays.
2.
On the Calibrate tab, complete the settings.
Setting Explanation
Seeds Per Disk The number of seed openings per disk plate.
Shaft Encoder Constant Pulses per revolution.
Calibration Constant A calculated value that the system determines during
calibration. This field allows you to adjust for
inconsistencies in the seed meters. To start out, leave the
value at 1.000. After the calibration test, the system may
adjust this number.
3. Tap Test and follow the instructions to test the settings you entered.
4. On the Limits tab, you can view an overview of the limits that are set.
Version 9.25, Revision B FM-1000 Integrated Display User Guide 235
