Equipment calibration for Field-IQ 9 Field-IQ system setup
1. Check that there is hydraulic flow to the Rawson.
2. At the Field-IQ Calibration screen, tap Hydraulic Test.
WARNING – Moving parts during this operation. Ensure the implement is safe to operate.
3. Tap Next.
4. Enter the initial motor RPM. The default setting is 300. It is recommended that you test the
motor RPM at 100 to ensure that the drive runs smoothly at slow speeds.
5.
Tap Start. The next screen provides the status of each motor:
ll No Error: The test was successful.
l Motor Stalled: The motors did not have sufficient oil flow. Ensure the correct orifice size is
installed for each motor. For more information, refer to the Rawson System Installation
Instructions.
l Disconnected: The Rawson Control Module cannot communicate with the motor.
6. Tap Stop to return to the Field-IQ Calibration screen.
PWM valves calibration
Drive Calibration
1. At the Field-IQ Calibration screen, select Drive Calibration. The Field-IQ Drive Calibration screen
displays.
2.
On the Drive Limits tab, enter the values for:
ll Minimum Seed Disk RPM
l Maximum Seed Disk RPM
Tap Next.
3.
On the Auto Tuning tab, follow the instructions to auto tune the system.
Note – Do not perform the auto tuning function if you have loaded a preset configuration file. Use the
predefined configuration settings appropriate for your vehicle.
WARNING – Moving parts during this operation. Ensure the implement is safe to operate.
During the auto tuning process the system tries to control the drive with in the specified RPM
limits.
If the calibration fails, the drive may have not been able to meet the limits you entered on the
Drive Limits tab.
For a liquid system, it may be helpful to remove all orifices or nozzles to let the system flow
freely.
234 FM-1000 Integrated Display User Guide Version 9.25, Revision B
