8 Vehicle guidance setup Manual guidance
3. In the Vehicle tab, complete the settings and tap OK.
Setting Explanation
Vehicle Type Type of vehicle
Axle to Antenna Offset
The horizontal distance between the axle and the antenna.
Measure the distance accurately (within 3 inches). An
incorrect offset may cause poor steering performance.
Note –
Measure the offset distance as accurately as possible
(within 3"); an incorrect offset may cause poor steering
performance.
ll If the antenna is in front of the axle, enter a forward
distance.
l If the antenna is behind the axle, enter a back distance.
Antenna Height Measure the antenna height vertically, from the ground to
the base of the antenna.
Wheelbase The horizontal distance between the center of the front
wheel and the center of the back wheel.
Note – Any changes you make to the vehicle settings remain, even if you replace the Manual Guidance
option with the Autopilot option.
4. Complete the GPS receiver settings (page 108).
Version 9.25, Revision B FM-1000 Integrated Display User Guide 165
