EZ-Pilot assisted steering system 8 Vehicle guidance setup
Setting Explanation
engage. If the vehicle approaches the swath at a distance
greater than this limit, it cannot be engaged.
Disengage offline Maximum distance from the swath at which the system can
remain engaged. If the vehicle drives offline greater than this
limit, the system disengages.
Coverage log
Displays on the Run screen to show what areas have been
applied.
l Select When Engaged to automatically show coverage
logging when the system is engaged. See Engage button
(page 351).
l Select Manual to show coverage logging only when you tap
.
Override sensitivity Amount the steering wheel must be turned manually before
the system disengages.
194 FM-1000 Integrated Display User Guide Version 9.25, Revision B
