Control setup 9 Field-IQ system setup
Setting Explanation
accuracy by selecting one or two offsets.
Row offsets are measured from the Application Offset value
entered in the Measurements tab of the Implement
Configuration wizard.
l Number of row offsets: Use 1 row offset when coverage is
applied at a single location. Use two row offsets when
planting singulated seed with staggered implements.
l Row Offset (1 row offset): Enter the distance between the
Application Offset and the row.
l Rear Row Offset (2 row offset): Enter the distance between the
Application Offset and the rear row.
l Front Row Offset (2 row offset): Enter the distance between the
Application Offset and the front row.
Material Controlled By You are controlling the material with:
l Switch Boxes
l On Screen
218 FM-1000 Integrated Display User Guide Version 9.25, Revision B
