9 Field-IQ system setup Equipment calibration for Field-IQ
Module drive calibration
The anhydrous valve calibration requires the vehicle and implement to be moving and the
implement must be in the ground (the implement lift switch must be down). Take all necessary
precautions to ensure user safety. Failure to do so may result in serious injury or death.
The Field-IQ system Calibrate option only displays on the Configuration screen if you have at least
one Field-IQ system Rawson control module or Rate control module set up to control the rate.
1. At the Configuration screen, select Field-IQ and tap Calibrate.
2.
At the Field-IQ Calibration screen, select the operation under the Module that you would like
to calibrate. The message "Not calibrated" displays at the end of the modules that need
calibration.
Note – If you have an implement lift switch, calibrate it first.
3. Select Drive Calibration and tap OK. The Drive Calibration screen displays.
4. At the Drive Limits tab, enter the minimum and maximum flow valves and tap Next.
5.
At the Drive Settings tab, turn the master switch on and vary the rates. Adjust the values if
needed. Enter the values for:
ll Allowable Error
l Integral Gain
l Minimum Response
6.
Tap Next and enter the following values for:
ll Allowable Error
l Gain
l Minimum Response
Note – For information about the appropriate values for your sprayer, refer to the support note Field-IQ
crop Input Control System: For Sprayers and Spreaders.
Module flow calibration
1. At the Field-IQCalibration screen, select Flow Calibration and tap OK.
2.
At the Rate and Section Control Flow Calibration screen, enter values for:
ll Flow Meter type
l Flow Meter Calibration
l Minimum Flow
3. Tap Run Calibration and follow the on-screen instructions.
