16 Water Management setup Tandem / dual scraper setup
Setting Explanation
Type
Tandem (Back): Default. Select to control two implements, one
towed behind the other.
Dual (Right): Select for a dual setup.
Antenna Height
Height of the antenna installed on either the rear implement,
or the antenna installed on the right side of a single
implement. Measure the antenna height vertically from the
ground to the base of the antenna.
Note –
For FieldLevel II, the antenna height value can be altered on
the Blade Settings tab and relates to the antenna installed on either
the front implement, or the antenna installed on the left side of a
single implement.
Disengage Raise
Used to control the rear implement or the right side of a single
implement when Auto is disengaged. If you set it to 0.000s
then the blade will not move up when you disengage.
Note –
For FieldLevel II, the disengage raise value can be altered
from the Blade Settings tab and relates to the front implement’s
blade, or the left side of the blade on a single implement.
Note –
For a tandem system, move the blade up when Auto is
disengaged on both the front and back implements as you will be
swapping between the two. For a dual setup with a single implement,
we recommend that you have the left and right Disengage Raise
values set to the same value.
Version 9.25, Revision B FM-1000 Integrated Display User Guide 309
