18 Operations Water Management functionality
l Composite Slope:The true angle of the fall of the design. In other words, the angle of the slope
when the two slope angles are combined.
l Slope Heading:The heading direction of the slope when the East/West and North/South slopes
are combined.
Create / save a design
After you complete the survey, the AutoPlane button displays on the Survey/Design panel.
To create a design for the optimum slope for your field that requires the minimum amount of dirt to
be moved:
1.
Tap AutoPlane. The AutoPlane screen displays.
If necessary, you can manually adjust the angle of the slope. However, this may require a
greater amount of dirt to be moved because the original design was the optimum.
2.
Complete the settings.
If necessary, you can manually adjust the angle of the slope. However, this may require a
greater amount of dirt to be moved because the original design was the optimum.
Setting Explanation
Cut/Fill Ratio The amount of cut material that equals one volume of fill
material.
Section
If you set up sections when you defined the field, you can
select a section from the list.
ll None:Levels the entire field.
l Left: Levels only the section to the left of the section
line.
l Right: Levels only the section to the right of the section
line.
Composite Slope The true angle of the fall of the design when the East/West
and North/South slopes are combined.
Slope Heading The heading direction of the slope when the East/West and
North/South slopes are combined.
North ->South Slope The angle of the design slope from North to South.
East ->West Slope The angle of the design slope from East to West.
Height or Cut/Fill
Height:Gives the design the theme of a topographic height
map.
Cut/Fill:Gives the design the theme of a cut/fill map. Red
Version 9.25, Revision B FM-1000 Integrated Display User Guide 435
