19 Diagnostics Yield Monitoring diagnostics
State 2 - During boot up
Cause Actions
Never sees the armrest, header
unit, moisture sensor, or reports
which one is not visible by the
display.
1. Ensure the display is communicating with the CAN bus
(system / diagnostics / serial port / Port A/B). Is there
another value other than zero for CAN messages?
2. For 60 Series Combines: Make sure Moisture Sensor has
version 1.20C loaded.
3. For 60 Series Combines: Check if Crop Type will change on
the Greenstar display after Crop Type on the FM-1000
integrated display has been changed.
4. For 70 Series Combines: Change the crop type in the
command center and make sure it changes on the FM-
1000 integrated display.
5. Raise head up or down to see if the display shows a
change for header height.
State 3 - During boot up
Cause Actions
Will show which controller is not
visible (armrest, header unit,
moisture sensor).
1. Ensure the display is communicating with the CAN bus
(system / diagnostics / serial port / Port A/B). Is there
another value other than zero for CAN messages?
2. For 60 Series Combines: Make sure Moisture Sensor has
version 1.20C loaded.
3. For 60 Series Combines: Check if Crop Type will change on
the Greenstar display after Crop Type on the FM-1000
integrated display has been changed.
4. For 70 Series Combines: Change the crop type in the
command center and make sure it changes on the FM-
1000 integrated display.
5. Raise head up or down to see if the display shows a
change for header height.
Version 9.25, Revision B FM-1000 Integrated Display User Guide 509
