4 Data management Data storage structure
Data Field Description Format / Notes
Roll The roll –
Speed GPS derived ground speed kph
Status_Text GPS status description –
Swath_Num Current swath/headland number
Swath_wdth Swath width meters
Target Target rate at the current position –
Target Target application rate when serial rate control,
TAC or the Field-IQ system are used
Total_Qty Total volume of material as applied for the
current field
Only supported for the:
l Aerial Flow Controller
l Autocal Flow controller
l Crophawk Flow Meter
–
TRACK_ID Date and time stamp –
Units Units metric
UTC_Date Point creation date YYYYMMDD
UTC_Time UTC time hh:mm:ss.s
Version Track attribute file version –
Yaw The yaw –
Graphical data formats
The FM-1000 integrated display uses the Environmental Systems Research Institute (ESRI) 3D shape-
file format for storing the layers of graphical information collected in the field (for example, spray
coverage, track logging points, and features). The three files in a shapefile set are:
l <filename>.dbf file: Contains the feature attributes
l <filename>.shp file:Contains position information
l <filename>.shx file: An index file that links the position information with its attributes
The term shapefile is used to refer to these three files collectively.
The display records all latitude, longitude, and height data in decimal degrees.
Version 9.25, Revision B FM-1000 Integrated Display User Guide 99
