Xerox VersaLink B7030 Service Manual

April 2017
6-12
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
GP 9
Launch Issue
General Procedures and Information
GP 9 How to Check a Switch
Purpose
Use this procedure to check the operation of a switch.
NOTE: The circuit in Figure 1 shows an interlock switch actuated by the closing of a door.
Initial Actions
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Manually check that the switch operates. Ensure that the magnet or other actuator has enough
mechanical movement to operate the switch.
NOTE: The voltages, PJ numbers, pin numbers and PWB names shown are an example only.
Procedure
• Disconnect PJA (Flag 1). Check the electrical operation of the switch.
• Disconnect PJB (Flag 1). Check for +5V and 0V on the IOT PWB.
• Check the wiring and the connectors for the switch circuit.
Figure 1 Wiring diagram

Xerox VersaLink B7030 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	1200 x 1200 dpi
Copy Speed	Up to 30 cpm
Copy Resolution	600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 kbps
Duplex Printing	Automatic
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android, Mopria
Control Panel	7-inch color touchscreen
Memory	2 GB
Print Speed	30 ppm
Supported Media Sizes	A4, A5, A6, B5, B6, Letter, Legal, Executive
Connectivity	USB, Ethernet, Wi-Fi
Processor	1 GHz
Scan Speed	Up to 55 ipm
