Xerox VersaLink B7030 Service Manual

April 2017
2-307
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
024-367, 024-368
Status Indicator RAPs
Launch Issue
024-367 Decompress Other Fail RAP
BSD-ON: BSD 3.9 ESS
024-367 Incorrect line synchronization was detected.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Switch off, then switch on the machine, GP 10.
2. Ensure the connectors on the hard disk are securely connected.
3. Format the hard disk drive, refer to dC355 Hard Disk Diagnostics.
4. Reload the software, GP 4.
5. Perform the OF2 Special Boot Modes RAP.
024-368 PCI Error RAP
BSD-ON: BSD 3.9 ESS
024-368 PCI access error occurred due to a faulty PCI bus.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Switch off, then switch on the machine, GP 10.
2. Ensure the connectors on the hard disk are securely connected.
3. Format the hard disk drive, refer to dC355 Hard Disk Diagnostics.
4. Reload the software, GP 4.
5. Perform the OF2 Special Boot Modes RAP.
