Xerox VersaLink B7030 Service Manual

April 2017
2-330
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
024-970, 024-972
Launch Issue
Status Indicator RAPs
024-970 Tray 6 Out of Place RAP
BSD-ON: BSD 7.14 HCF Paper Size Sensing and Tray Set
024-970 Tray 6 out of place.
Initial Actions
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Switch off, then switch on the machine, GP 10.
Procedure
Enter dC330, code 078-204, HCF tray in sensor. Manually actuate the HCF tray in sensor, PL
70.45 Item 3.
The display changes.
YN
Check the HCF tray in sensor. Refer to GP 7 How to Check a Sensor.
Check for damage to the actuator on the HCF tray. If the fault persists, install new components
as necessary:
• HCF tray in sensor, PL 70.45 Item 3.
• HCF PWB, PL 70.60 Item 9.
024-972 Tray 6 Size Mismatch RAP
BSD-ON: BSD 7.14 HCF Paper Size Sensing and Tray Set
024-972 Tray 6 size mismatch.
Initial Actions
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
• Ensure that the HCF is loaded correctly and the paper guides correctly set.
• Switch off, then switch on the machine, GP 10.
Procedure
Enter dC330, code 078-202, HCF size sensor A. Manually actuate the HCF size sensor A, PL
70.60 Item 11.
The display changes.
YN
Check the HCF size sensor A. Refer to GP 7 How to Check a Sensor.
Enter dC330, code 078-203, HCF size sensor B. Manually actuate the HCF size sensor B, PL
70.60 Item 11.
The display changes.
YN
Check the HCF size sensor B. Refer to GP 7 How to Check a Sensor.
Check for damage to the actuator on the HCF tray. If the fault persists, install new components
as necessary:
• HCF size sensor A, PL 70.60 Item 11.
• HCF size sensor B, PL 70.60 Item 11.
• HCF PWB, PL 70.60 Item 9.
