April 2017
2-171
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
016-604, 016-606, 016-608
Status Indicator RAPs
Launch Issue
016-604 Debug Log Created RAP
016-604 Debug log auto creation by system.
Procedure
Switch off, then switch on the machine, GP 10.
016-606, 016-608 Controller Connection Fail RAP
016-606 Cont-BP cable connection fail.
016-608 Cont-drive PWB cable connection fail.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Switch off, then switch on the machine, GP 10.
2. Ensure that all connectors on the drive PWB, PL 1.10 Item 3 and the ESS PWB, PL 3.10
Item 6 are securely connected. Ensure all surface mounted modules on both PWBs are
securely connected.
3. Reload the software, GP 4.
4. If the fault persists, install a new components as necessary:
• ESS PWB, PL 3.10 Item 6.
• Drive PWB, PL 1.10 Item 3.
To Next Page
