Xerox VersaLink B7030 Service Manual

April 2017
2-481
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
077-300, 077-301
Status Indicator RAPs
Launch Issue
077-300 Front Cover Open RAP
BSD-ON: BSD 1.8 Power Interlock Switching (1 of 3)
077-300 Front cover was opened during run.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Refer to the procedure that follows as necessary:
• GP 9 How to Check a Switch
Perform the steps that follow:
1. Check the actuator on the front cover for damage. If necessary, install a new front cover,
PL 28.05 Item 2.
2. Enter dC330 code 077-303. Check the front cover interlock switch, PL 1.05 Item 4.
3. If the fault persists, install new components as necessary:
• LVPS, PL 1.10 Item 8.
•Drive PWB, PL 1.10 Item 3.
• ESS PWB, PL 3.10 Item 6.
077-301 L/H Cover Open RAP
BSD-ON: BSD 1.8 Power Interlock Switching (1 of 3)
077-301 L/H cover was opened during run.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Refer to the procedure that follows as necessary:
• GP 9 How to Check a Switch
Perform the steps that follow:
1. Check the actuator on the L/H cover for damage. If necessary, install a new L/H cover, PL
80.40 Item 8.
2. Enter dC330 code 077-300. Check the left hand cover interlock switch, PL 80.40 Item 1.
3. If the fault persists, install new components as necessary:
• LVPS, PL 1.10 Item 8.
• Drive PWB, PL 1.10 Item 3.
• ESS PWB, PL 3.10 Item 6.
