Xerox VersaLink B7030 Service Manual

April 2017
2-450
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
045-310, 045-311, 045-396
Launch Issue
Status Indicator RAPs
045-310 Image Ready RAP
045-310 Controller image preparation failure detected.
Procedure
1. Switch off, then switch on the machine, GP 10.
2. Reload the software, GP 4.
045-311, 045-396 Controller Communication Fail RAP
BSD-ON: BSD 3.1 PWB Communications (ESS PWB to Drive PWB)
045-311 Communication failure between ESS PWB and DRIVE PWB was detected.
045-396 IO setup error of HASIC installed on drive PWB.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Switch off, then switch on the machine, GP 10.
2. Check the connection between the ESS PWB ( P/J1334) and the drive PWB ( P/J401).
3. Install new components as necessary:
• ESS PWB, PL 3.10 Item 6.
• Drive PWB, PL 1.10 Item 3.

Xerox VersaLink B7030 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	1200 x 1200 dpi
Copy Speed	Up to 30 cpm
Copy Resolution	600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 kbps
Duplex Printing	Automatic
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android, Mopria
Control Panel	7-inch color touchscreen
Memory	2 GB
Print Speed	30 ppm
Supported Media Sizes	A4, A5, A6, B5, B6, Letter, Legal, Executive
Connectivity	USB, Ethernet, Wi-Fi
Processor	1 GHz
Scan Speed	Up to 55 ipm
