April 2017
2-303
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
024-322, 024-323, 024-340 to 024-360
Status Indicator RAPs
Launch Issue
024-322, 024-323 SEEPROM Refurbish RAP
BSD-ON: BSD 3.1 PWB Communications (ESS PWB to Drive PWB)
024-322 A backup data read error was detected.
024-323 When restore was requested, it was detected that the backup data did not exist.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Switch off, then switch on the machine, GP 10.
2. Ensure that all connectors on the drive PWB, PL 1.10 Item 3 and the ESS PWB, PL 3.10
Item 6 are securely connected. Ensure all surface mounted modules on both PWBs are
securely connected.
3. Reload the software, GP 4.
4. Perform the OF2 Special Boot Modes RAP.
5. If the fault persists, install new components as necessary:
•Drive PWB, PL 1.10 Item 3.
• ESS PWB, PL 3.10 Item 6.
024-340 to 024-360 IOT-ESS Communication Fail 1 RAP
BSD-ON: BSD 3.1 PWB Communications (ESS PWB to Drive PWB)
024-340 Sending error detected by controller (invalid parameter was used).
024-341 Sending error detected by controller (sequence number error).
024-342 Sending error detected by controller (packet number error).
024-343 Sending error detected by controller (message length error).
024-345 Sending error detected by controller (check code error).
024-346 Sending error detected by controller (parity error detected by the IOT.
024-347 Sending error detected by controller (framing error detected by the IOT).
024-348 Sending error detected by controller (overrun error detected by the IOT).
024-349 Sending error detected by controller (receive abort detected by the IOT after the
header had been recognized).
024-350 Receiving error detected by controller (sequence number of the received message
packet is incorrect).
024-351 Receiving error detected by controller (packet number error).
024-352 Receiving error detected by controller (message length error).
024-353 Receiving error detected by controller (check code error).
024-354 Receiving error detected by controller (parity error detected by the UART).
024-355 Receiving error detected by controller (framing error detected by the UART).
024-356 Receiving overrun error detected by controller (overrun error detected by the UART).
024-357 Receiving error detected by controller (receiving abort detected after the header had
been recognized).
024-358 Print sequence error detected by controller (paper feed and paper output that are not
applicable to the number detected.)
024-359 Transmission receiving error detected by controller (invalid parameter used).
024-360 Initialization error between IOT and ESS.
