April 2017
2-309
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
024-374, 024-376
Status Indicator RAPs
Launch Issue
024-374 RegiCon PLL Parameter Fail RAP
BSD-ON: BSD 3.1 PWB Communications (ESS PWB to Drive PWB)
024-374 RegiCon adjustment value setting error detected by the controller (incorrect parame-
ter instruction).
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Switch off, then switch on the machine, GP 10.
2. Ensure that all connectors on the drive PWB, PL 1.10 Item 3 and the ESS PWB, PL 3.10
Item 6 are securely connected. Ensure all surface mounted modules on both PWBs are
securely connected.
3. Reload the software, GP 4.
4. If the fault persists, install new components as necessary:
•Drive PWB, PL 1.10 Item 3.
• ESS PWB, PL 3.10 Item 6.
024-376 IOT-ESS Communication Fail 3 RAP
BSD-ON: BSD 3.1 PWB Communications (ESS PWB to Drive PWB)
BSD-ON: BSD 6.4 Laser Control
024-376 Image signal truncation detected by the controller.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Switch off, then switch on the machine, GP 10.
2. Ensure that all connectors on the drive PWB, PL 1.10 Item 3 and the ESS PWB, PL 3.10
Item 6 are securely connected. Ensure all surface mounted modules on both PWBs are
securely connected.
3. Check the FFC ribbon cable between the ESS PWB and the LPH, PL 60.35 Item 9.
4. Reload the software, GP 4.
5. Perform the OF2 Special Boot Modes RAP.
6. If the fault persists, install new components as necessary:
• Drive PWB, PL 1.10 Item 3.
• ESS PWB, PL 3.10 Item 6.
To Next Page
