Xerox VersaLink B7030 Service Manual

April 2017
2-135
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
016-500, 016-501, 016-502
Status Indicator RAPs
Launch Issue
016-500, 016-501 ROM Write Error (During DLD Method)
RAP
016-500 An error has occurred during the process of writing data to the cont-ROM.
016-501 An error has occurred during the process of writing data to the S2X-ROM.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Reload the software, GP 4.
2. If the fault persists, install a new ESS PWB, PL 3.10 Item 6.
016-502 ROM Write Error (During PJL Method) RAP
016-502 An error was detected when writing data to one of the ROMs in the machine.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Ensure that all connectors on the ESS PWB, PL 3.10 Item 6 are securely connected.
Ensure all surface mounted modules are securely connected.
2. Reload the software, GP 4.
3. If the fault persists, install a new ESS PWB, PL 3.10 Item 6.

Xerox VersaLink B7030 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	1200 x 1200 dpi
Copy Speed	Up to 30 cpm
Copy Resolution	600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 kbps
Duplex Printing	Automatic
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android, Mopria
Control Panel	7-inch color touchscreen
Memory	2 GB
Print Speed	30 ppm
Supported Media Sizes	A4, A5, A6, B5, B6, Letter, Legal, Executive
Connectivity	USB, Ethernet, Wi-Fi
Processor	1 GHz
Scan Speed	Up to 55 ipm
