Xerox VersaLink B7030 Service Manual

April 2017
2-312
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
024-701, 024-702
Launch Issue
Status Indicator RAPs
024-701 Invalid Instruction of Face Inversion RAP
024-701 Job cancellation due to invalid invert instruction.
Procedure
Advise the customer to use paper that is in specification. Refer to GP 15 Paper and Media Size
Specifications.
024-702 Paper Jam RAP
024-702 Job cancellation due to paper jam.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Check the sensors that follow:
• Tray 2 feed out sensor. Refer to the 073-106 Tray 2 Feed Out Sensor RAP.
• Tray 4 feed out sensor. Refer to the 074-101, 103, 900 Tray 4 Misfeed RAP.
• Registration sensor. Refer to the 071-105 Registration Sensor Jam (Tray 1) RAP.
• Fuser Unit exit sensor. Refer to the 077-104, 109, 113, 901 Fuser Exit Sensor Jam RAP.
• Exit 2 sensor. Refer to the 077-105 Exit Sensor 2 Jam RAP.

Xerox VersaLink B7030 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	1200 x 1200 dpi
Copy Speed	Up to 30 cpm
Copy Resolution	600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 kbps
Duplex Printing	Automatic
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android, Mopria
Control Panel	7-inch color touchscreen
Memory	2 GB
Print Speed	30 ppm
Supported Media Sizes	A4, A5, A6, B5, B6, Letter, Legal, Executive
Connectivity	USB, Ethernet, Wi-Fi
Processor	1 GHz
Scan Speed	Up to 55 ipm
