Xerox VersaLink B7030 Service Manual

April 2017
3-15
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
IQ16
Imaqe Quality
Launch Issue
IQ16 Regular Toner Contamination in the Process
Direction (Side 2) RAP
Regular pitch toner contamination in the process direction. Refer to Figure 1.
Ensure IQ1 Image Quality Entry RAP is performed before starting this RAP.
Figure 1 Example
Cause
1. 95.1mm (3.7 inches) pitch - scratch or foreign substance on the fusing belt.
2. 50.3mm (2 inches) pitch - contamination or scratches on the BTR. Paper size mismatch
3. 37.7mm pitch - contamination on the BCR.
Action
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
1. For cause 1, install a new fuser, PL 10.05 Item 2.
2. For cause 2:
a. Check the paper tray settings.
b. Clean the BTR. If necessary, install a new BTR assembly, PL 90.15 Item 4.
3. For cause 3, install a new drum cartridge, PL 90.20 Item 1.

Xerox VersaLink B7030 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	1200 x 1200 dpi
Copy Speed	Up to 30 cpm
Copy Resolution	600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 kbps
Duplex Printing	Automatic
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android, Mopria
Control Panel	7-inch color touchscreen
Memory	2 GB
Print Speed	30 ppm
Supported Media Sizes	A4, A5, A6, B5, B6, Letter, Legal, Executive
Connectivity	USB, Ethernet, Wi-Fi
Processor	1 GHz
Scan Speed	Up to 55 ipm
