April 2017
2-473
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
073-106, 073-210
Status Indicator RAPs
Launch Issue
073-106 Tray 2 Feed Out Sensor RAP
073-106 Paper does not deactuate the tray 2 feed out sensor within the specified time after
each tray feed start.
Procedure
Perform the 072-101, 072-900 Tray 2 Misfeed RAP.
073-210 Tray 3 Lift Fail RAP
BSD-ON: BSD 7.11 Tray 3 Paper Stacking (3TM)
BSD-ON: BSD 7.20 Tray 3 Paper Stacking (TTM)
073-210 Tray 3 lift NG has occurred three consecutive times.
Initial Actions
• Check for obstructions behind the tray.
• Ensure that the tray is loaded correctly.
• Ensure the tray is pushed fully home.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Refer to the procedures that follow as necessary:
• GP 6 How to Check a Motor.
• GP 7 How to Check a Sensor.
Perform the steps that follow:
1. Enter dC330, code 073-102. Check the tray 3 level sensor, PL 80.20 Item 6.
2. Enter dC330, code 073-002. Check the tray 3 feed/lift up motor, PL 80.20 Item 4.
3. Enter dC330, code 042-003. Check the main motor,PL 40.10 Item 1.
4. Check the drive gears, PL 80.20 for wear or damage. Install new components as neces-
sary.
5. (3TM Only) Check the drive system between the bottom plate and the tray 3 feed/lift
motor for operation failure. Install new components as necessary, PL 70.20.
6. (TTM Only) Check the drive system between the bottom plate and the tray 3 feed/lift
motor for operation failure. Also check the bottom plate lift mechanism. Install new com
-
ponents as necessary, PL 70.66.
7. If the fault persists, install new components as necessary:
•3TM PWB, PL 70.23 Item 5.
• TTM PWB, PL 70.90 Item 1.
To Next Page
