April 2017
4-99
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
REP 13.7, REP 13.8
Repairs and Adjustments
Launch Issue
REP 13.7 Rear Upper Cover
Parts List on PL 13.10
Removal
WARNING
Switch off the electricity to the machine. Refer to GP 10. Disconnect the power cord
from the customer supply while performing tasks that do not need electricity. Electricity
can cause death or injury. Moving parts can cause injury.
1. Undock the finisher, REP 13.5.
2. Remove the booklet maker, REP 13.31.
3. Remove four screws, then the rear upper cover, PL 13.10 Item 9.
Replacement
The replacement is the reverse of the removal procedure.
REP 13.8 Rear Lower Cover
Parts List on PL 13.10
Removal
WARNING
Switch off the electricity to the machine. Refer to GP 10. Disconnect the power cord
from the customer supply while performing tasks that do not need electricity. Electricity
can cause death or injury. Moving parts can cause injury.
1. Undock the finisher, REP 13.5.
2. Remove three screws, then the rear lower cover, PL 13.10 Item 8.
Replacement
The replacement is the reverse of the removal procedure.
