April 2017
2-58
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
012-132A, 012-151
Launch Issue
Status Indicator RAPs
YN
Check the +5VDC circuit. Refer to the Wiring Diagrams.
Measure the voltage between the finisher PWB P/J8709 pin 5 (+) and ground (-). Actuate
the finisher entrance sensor.
The voltage changes.
YN
Install a new finisher entrance sensor, PL 12.12 Item 19.
Check the wires and connectors for an intermittent open or short circuit. If the fault per-
sists, install a new finisher PWB, PL 12.14 Item 1.
Check the wires and connectors for an intermittent open or short circuit. If the fault persists,
install a new finisher PWB, PL 12.14 Item 1.
012-151 Compiler Exit Sensor Off Jam Entry RAP
012-151 The compiler exit sensor does not deatuate within a specified time.
Procedure
Go to the relevant procedure:
• Integrated office finisher installed, 012-151A Compiler Exit Sensor Off Jam RAP.
• Office finisher LX installed, 012-151B, 012-152B Compiler Exit Sensor Off Jam RAP.
A
