April 2017
6-49
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
dC301, dC305
General Procedures and Information
Launch Issue
dC301 NVM Initialization
Purpose
To reset the values of all applicable NVM parameters to default.
Procedure
1. Enter Diagnostics, GP 1.
2. Touch dC301 Initialize NVM.
3. Select the area to be initialized. Refer to Table 1.
4. Touch Start.
5. Follow the UI messages to initialize the NVM.
6. Touch Close to return to the Diagnostics screen.
7. Enter dC131. Ensure NVM value 790-900 is set to 1. If the NVM value had to be changed,
switch off, then switch on the machine, GP 10. Verify that the Embedded Web Server is
working.
8. Exit diagnostics, GP 1.
dC305 UI Panel Diagnostics
Purpose
To test the LED and audio functions of the user interface.
Procedure
1. Enter Diagnostics, GP 1.
2. Touch dC305 UI Panel Diagnostics.
3. Touch LED Test or Audio Test.
4. Exit diagnostics, GP 1.
LED Test
1. Touch the 1 or more LEDs to be diagnosed:
• Interactive
• Error
•NFC
• Power
•Data
2. Touch the display pattern to be diagnosed. The selected LEDs are switched on.
3. Touch All Off.
4. Touch the back button (top left) to return to the Diagnostics screen.
Audio Test
1. Touch Volume. Adjust the volume as necessary.
2. Touch the pattern to be diagnosed. The audio sounds with the specified volume and pat-
tern:
• Pattern 1
• Pattern 2
• Pattern 3
• Pattern 4
• Pattern 5
• Pattern 6
3. Touch the back button (top left) to return to the Diagnostics screen.
Table 1 NVM areas
Area Comments
IOT 1 Drive PWB NVM. After initializing the IOT 1 NVM, ensure the tray module
type is correctly set, refer to the 077-211 Tray Module Mismatch RAP.
IOT 2 Do not use.
Finisher Integrated finisher or LX office finisher NVM.
IFM Do not use.
IISS - IIT/IPS Scanner NVM.
IISS - Extension Do not use.
Input Device DADF NVM.
Sys - System ESS PWB NVM.
Sys - User SD card customer settings. The installation wizard will have to be run
after initializing the SD card NVM.
Fault Counter Fault history.
HCS 1 Do not use.
HCS 2 Do not use.
PFIM Do not use.
