Xerox VersaLink B7030 Service Manual

April 2017
2-443
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
041-310, 041-333
Status Indicator RAPs
Launch Issue
041-310 IM Logic Fail RAP
BSD-ON: BSD 3.1 PWB Communications (ESS PWB to Drive PWB)
041-310 IM software control error detected.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Switch off, then switch on the machine, GP 10.
2. Reload the software, GP 4.
3. If the fault persists, install new components as necessary:
•Drive PWB, PL 1.10 Item 3.
• ESS PWB, PL 3.10 Item 6.
041-333 Drive PWB F10 Blown RAP
BSD-ON: BSD 1.5 DC Power Generation (2 of 2)
BSD-ON: BSD 1.7 Option DC Power Distribution
041-333 Drive PWB fuse 10 open circuit was detected.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Check the tray module for overcurrent and overvoltage. Repair the wiring or install new
components as necessary.
2. After the faulty circuit has been repaired, install a new drive PWB, PL 1.10 Item 3.

Xerox VersaLink B7030 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	1200 x 1200 dpi
Copy Speed	Up to 30 cpm
Copy Resolution	600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 kbps
Duplex Printing	Automatic
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android, Mopria
Control Panel	7-inch color touchscreen
Memory	2 GB
Print Speed	30 ppm
Supported Media Sizes	A4, A5, A6, B5, B6, Letter, Legal, Executive
Connectivity	USB, Ethernet, Wi-Fi
Processor	1 GHz
Scan Speed	Up to 55 ipm
