Xerox VersaLink B7030

April 2017
2-118
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
016-326, 016-607, 016-327, 016-328
Launch Issue
Status Indicator RAPs
016-326, 016-607 UI Cable Connection Fail RAP
BSD-ON: BSD 2.1 Control Panel
016-326 The controller has detected a failure at its cable connection with the UI.
016-607 Cont-UI Cable Connection Fail
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Check the wiring between the ESS PWB and the UI
2. Install new components as necessary:
• ESS PWB, PL 3.10 Item 6.
• UI assembly, PL 2.05 Item 7.
016-327, 016-328 Connection Fail RAP
016-327 Backplane connection fail.
016-328 The controller has detected a failure at its cable connection with the MCU.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Switch off, then switch on the machine, GP 10.
2. Ensure that all connectors on the ESS PWB, PL 3.10 Item 6 are securely connected.
Ensure all surface mounted modules are securely connected.
3. Reload the software, GP 4.
