Xerox VersaLink B7030 Service Manual

April 2017
2-540
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
117-344, 117-345
Launch Issue
Status Indicator RAPs
117-344 Invalid User Job Type Fail RAP
117-344 The applicable user job cannot be executed at the system level.
Procedure
Advise the customer to check if public print it is set to be stored as charge print.
117-345 SSMM Batch Setting Duration Fail RAP
117-345 During the batch setting of LoDeM, a reboot occurred due to a change in system data.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
1. For a single occurrence, take no action.
2. If the fault persists, perform the steps that follow:
a. Switch off, then switch on the machine, GP 10.
b. Ensure that all connectors on the drive PWB, PL 1.10 Item 3 and the ESS PWB, PL
3.10 Item 6 are securely connected. Ensure all surface mounted modules on both
PWBs are securely connected.
c. Reload the software, GP 4.
d. Perform the OF2 Special Boot Modes RAP.

Xerox VersaLink B7030 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	1200 x 1200 dpi
Copy Speed	Up to 30 cpm
Copy Resolution	600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 kbps
Duplex Printing	Automatic
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android, Mopria
Control Panel	7-inch color touchscreen
Memory	2 GB
Print Speed	30 ppm
Supported Media Sizes	A4, A5, A6, B5, B6, Letter, Legal, Executive
Connectivity	USB, Ethernet, Wi-Fi
Processor	1 GHz
Scan Speed	Up to 55 ipm
