Xerox VersaLink B7030 Service Manual

April 2017
2-102
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
013-307
Launch Issue
Status Indicator RAPs
013-307 Booklet Left Cover Open RAP
BSD-ON: BSD 13.4 Office Finisher LX Booklet Interlock Switching
013-307 Control logic senses that the booklet left cover is open.
Initial Actions
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Ensure the left cover, PL 13.50 Item 8 is closed.
Procedure
Measure the voltage between P/J8993 pin 5 on the booklet PWB and ground. +24VDC is
measured.
YN
Check the circuit from P/J8993 to and from J8899 on the booklet stapler cover switch,
PL 13.70 Item 10.
Install a new booklet PWB, PL 13.70 Item 4.

Xerox VersaLink B7030 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	1200 x 1200 dpi
Copy Speed	Up to 30 cpm
Copy Resolution	600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 kbps
Duplex Printing	Automatic
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android, Mopria
Control Panel	7-inch color touchscreen
Memory	2 GB
Print Speed	30 ppm
Supported Media Sizes	A4, A5, A6, B5, B6, Letter, Legal, Executive
Connectivity	USB, Ethernet, Wi-Fi
Processor	1 GHz
Scan Speed	Up to 55 ipm
