April 2017
2-123
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
016-360, 016-362, 016-363
Status Indicator RAPs
Launch Issue
016-360, 016-362 Controller UI Fail RAP
016-360 Cont UI diagnostic fail 1.
016-362 Cont UI diagnostic fail 2.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Switch off, then switch on the machine, GP 10.
2. Check the wiring between the ESS PWB and the UI
3. Install new components as necessary:
• ESS PWB, PL 3.10 Item 6.
• UI assembly, PL 2.05 Item 7.
016-363 Controller LyraCard Fail RAP
016-363 Cont JPEG card diagnosed as having a failure.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Switch off, then switch on the machine, GP 10.
2. Ensure that all connectors on the ESS PWB, PL 3.10 Item 6 are securely connected.
Ensure all surface mounted modules are securely connected.
3. Reload the software, GP 4.
4. If the fault persists, install a new ESS PWB, PL 3.10 Item 6.
To Next Page
