April 2017
2-89
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
012-243, 012-265, 012-249
Status Indicator RAPs
Launch Issue
012-243, 012-265 Booklet Folder Home Sensor Fail RAP
BSD-ON: BSD 13.8 Office Finisher LX Folding
012-243 Folder home sensor is not actuated after the lapse of 500ms from motor on while
folder knife is returning to home.
012-265 When the booklet home moves from home position, the folder home sensor did not
turn off within the specified time.
Initial Actions
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
• Check the folder home sensor, PL 13.40 Item 16 for improper installation.
• Check the knife drive mechanism, PL 13.40 for a foreign substance.
Procedure
Enter dC330 code 013-022 and 013-023 alternately to run the folder knife motor. The fold
knife motor runs.
YN
Check the wiring between P/J8905 and P/J8990 on the finisher PWB and between P/
J8994 on the booklet PWB and J8985 on the finisher PWB for an open or short circuit, or
a loose or damaged connector.
The wiring is good.
YN
Reconnect or repair as necessary.
Install a new booklet folder knife motor, PL 13.40 Item 15. If the fault persists, install a
new booklet PWB, PL 13.70 Item 4.
Enter dC330 code 13-101. Actuate the folder home sensor. The display changes.
YN
Check the wiring between J8904 pin 2 and P/J8990 pin 2 on the finisher PWB for an
open or short circuit, or a loose or damaged connector.
The wiring is good.
YN
Reconnect or repair as necessary.
Measure the voltage between P/J8990 pins 3 and 1 on the finisher PWB. The voltage is
approximately +5VDC.
YN
Install a new finisher PWB, PL 13.45 Item 2.
Measure the voltage between P/J8990 pin 2 on the finisher PWB and ground. Actuate
the folder home sensor.
The voltage changes.
YN
Install a new folder home sensor, PL 13.40 Item 16.
Install a new finisher PWB, PL 13.45 Item 2.
If the fault persists, install a new finisher PWB, PL 13.45 Item 2.
012-249 Booklet Front Stapler Fail RAP
BSD-ON: BSD 13.4 Office Finisher LX Booklet Interlock Switching
BSD-ON: BSD 13.17 Office Finisher LX Booklet Staple Control (1 of 2 - Front)
012-249 The booklet front staple home switch is not on (does not return to home position)
within the specified time after the booklet front staple motor starts to reverse.
Initial Actions
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Check the booklet front stapler for jammed staples or an incorrectly installed staple cartridge.
Procedure
Enter dC330 code 12-024 then 12-025 to cycle the front booklet stapler. The front booklet
stapler cycles normally.
YN
Measure the voltage between P/J8993 pin 5 on the booklet PWB and ground. The volt-
age is approximately +24VDC.
YN
Check the circuit from the booklet PWB to the booklet stapler cover switch. Repair
the wiring or install new components as necessary, PL 13.70.
Switch off the machine, GP 10. Check the wiring between P/J8995 on the booklet PWB
and J8894 on the front booklet stapler for a loose or damaged connector, or an open or
short circuit. If the wiring is good, install a new front booklet stapler assembly, PL 13.60
Item 13. If the problem persists, install a new booklet PWB, PL 13.70 Item 4.
Switch off the machine, GP 10. Check the wiring between P/J8995 pin 5 on the booklet PWB
and P/J8994 pin 3 on the front booklet stapler for a loose or damaged connector, or an open
or short circuit. If the wiring is good, install a new front booklet stapler assembly, PL 13.60 Item
13. If the problem persists, install a new booklet PWB, PL 13.70 Item 4.
To Next Page
