Xerox VersaLink B7030 Service Manual

April 2017
2-57
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
012-132, 012-132A
Status Indicator RAPs
Launch Issue
012-132 Entrance Sensor On Jam Entry RAP
012-132 Finisher entrance sensor does not actuate within a specified time after receiving the
sheet exit command (the sheet to be ejected has actuated the IOT exit sensor 1).
Procedure
Go to the relevant procedure:
• Integrated office finisher installed, 012-132A Entrance Sensor On Jam RAP.
• Office finisher LX installed, 012-132B Entrance Sensor On Jam RAP.
012-132A Entrance Sensor On Jam RAP
BSD-ON: BSD 12.3 Integrated Office Finisher Transportation
Initial Actions
NOTE: Ensure the correct RAP is performed, refer to the 012-132 Entrance Sensor On Jam
Entry RAP.
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
• Check that the finisher entrance sensor, PL 12.12 Item 19 is correctly installed and free
from foreign objects and that the actuator is not broken.
• Switch off, then switch on the machine, GP 10.
Procedure
Check the specifications of paper, GP 15. Paper is in specification.
YN
Load paper that is in specification.
Check the condition of the paper. The paper is in normal condition without any problem
that causes the paper to be bent or caught.
YN
Resolve any problem that causes the paper to be bent or caught.
Check the transport path for a foreign object, deformed part or paper dust. The transport
path is good.
YN
Repair the deformed part(s) or remove the foreign object(s) and paper dust.
Check that the finisher is installed correctly. The finisher is correctly installed and correctly
connected to the IOT.
YN
Reinstall the finisher correctly.
Enter dC330 code 012-140. Actuate the finisher entrance sensor. The display changes.
YN
Check the connections of P/J8709 and P/J8729. The connectors are good.
YN
Secure the connections.
Check for an open or short circuit between P/J8709 and P/J8729. The wiring is good.
YN
Repair the open or short circuit.
Measure the voltage between the finisher PWB P/J8709 pin 6 (+) and ground (-). The
voltage is approximately +5VDC.
A
