Xerox VersaLink B7030 Service Manual

April 2017
2-119
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
016-330, 331, 332, 016-335 to 016-351
Status Indicator RAPs
Launch Issue
016-330, 331, 332 Cont System Memory Fail RAP
016-330 Cont system memory diagnostic fail 1.
016-331 Cont system memory diagnostic fail 2.
016-332 Cont system memory diagnostic fail 3.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Switch off, then switch on the machine, GP 10.
2. Ensure that all connectors on the ESS PWB, PL 3.10 Item 6 are securely connected.
Ensure all surface mounted modules are securely connected.
3. Reload the software, GP 4.
4. If the fault persists, install a new ESS PWB, PL 3.10 Item 6.
016-335 to 016-351 Controller Fail RAP
016-335 Cont program ROM diagnostic fail 1.
016-336 Cont program ROM diagnostic fail 2.
016-337 Cont program ROM diagnostic fail 3.
016-338 Cont font ROM diagnostic fail 1.
016-339 Cont font ROM diagnostic fail 2.
016-340 Cont font ROM diagnostic fail 3.
016-341 Cont font ROM diagnostic fail 4.
016-342 Cont RTC diagnostic fail.
016-343 Long boot diag timer fail.
016-345 Cont NVM diagnostic fail.
016-346 Cont A4 fax modem diagnosis fail.
016-347 Cont page memory diagnostic fail 1.
016-348 Cont page memory fail 2.
016-349 Cont MAC address data fail.
016-350 Cont SEEP-ROM diagnostic fail 1.
016-351 Cont SEEP-ROM diagnostic fail 2.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Switch off, then switch on the machine, GP 10.
2. Ensure that all connectors on the ESS PWB, PL 3.10 Item 6 are securely connected.
Ensure all surface mounted modules are securely connected.
3. Reload the software, GP 4.
4. If the fault persists, install a new ESS PWB, PL 3.10 Item 6.
