Xerox VersaLink B7030 Service Manual

April 2017
8-93
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
Product Technical Overview
Launch Issue
Hole Punch Box
The punch box is located beneath the hole punch assembly and collects the discarded chads.
This will need to be emptied periodically. Refer to Figure 48.
Figure 48 Hole punch box
Customer Replaceable Units
Refer to Figure 49. The only customer replaceable units (CRUs) for the LX finisher are:
• The 5,000 stitch staple cartridge and
• The two staple cassettes for the booklet maker. Each of the staple cassettes holds 2,000
staples.
Figure 49 Customer replaceable units
Punch box
