Xerox VersaLink B7030 Service Manual

April 2017
2-564
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
124-341, 351, 361, 381, 391, 124-342, 343, 352, 353,
Launch Issue
Status Indicator RAPs
124-341, 351, 361, 381, 391 CRUM Market Fail RAP
124-341 One of CRUM destinations is different from the others (IOT).
124-351 One of CRUM OEM destinations is different from the others (IOT).
124-361 One of CRUM Enable/Disable settings is different from the others (IOT).
124-381 One of CRUM destinations is different from the others (IOT).
124-391 One of CRUM OEM destinations is different from the others (IOT).
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Switch off, then switch on the machine, GP 10.
2. Enter dC132 Device ID and Billing Data. Make all three values the same.
3. If the fault persists, install a new drive PWB, PL 1.10 Item 3.
124-342, 343, 352, 353, 362, 363, 382, 383, 392, 393 CRUM
Market Fail SYS 1 RAP
124-342 One of CRUM destinations is different from the others (SYS 1).
124-343 One of CRUM destinations is different from the others (SYS 2).
124-352 One of CRUM OEM destinations is different from the others (SYS 1).
124-353 One of CRUM OEM destinations is different from the others (SYS 2).
124-362 One of CRUM enable/disable settings is different from the others (SYS 1).
124-363 One of CRUM enable/disable settings is different from the others (SYS 2).
124-382 One of CRUM destinations is different from the others (SYS 1).
124-383 One of CRUM destinations is different from the others (SYS 2).
124-392 One of CRUM OEM destinations is different from the others (SYS 1).
124-393 One of CRUM OEM destinations is different from the others (SYS 2).
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Switch off, then switch on the machine, GP 10. The fault persists.
YN
Perform SCP 5 Final Actions.
Enter dC132 Device ID and Billing Data. Make all three product numbers the same. The fault
persists.
YN
Perform SCP 5 Final Actions.
Reinstall the SD card, PL 3.10 Item 11. The fault persists.
YN
Perform SCP 5 Final Actions.
Install a new SD card, PL 3.10 Item 11. The fault persists.
YN
Perform SCP 5 Final Actions.
Install a new ESS PWB, PL 3.10 Item 6.
