012-283A, 012-284A Set Clamp Home Sensor Fail RAP
BSD-ON: BSD 12.7 Integrated Office Finisher Set Eject (2 of 2)
Initial Actions
NOTE: Ensure the correct RAP is performed, refer to the 012-283, 012-284 Set Clamp Home
Sensor Fail Entry RAP.
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
• Check the set clamp home sensor, PL 12.11 Item 7 is correctly installed and has no for-
eign object and that the actuator is not broken.
• Switch off, then switch on the machine, GP 10.
Procedure
Check the set clamp mechanism, PL 12.25 for a deformed or broken part and not-seated
belts.
The mechanism is good.
YN
Repair the set clamp mechanism. Install new components as necessary, PL 12.25.
Enter dC330 code 012-251. Manually rotate the set clamp shaft to actuate the set clamp home
sensor.
The display changes.
YN
Check the connections of P/J8707, J8742A, J8742B and P/J8723. The connectors
are good.
YN
Secure the connections.
Check for an open or short circuit between P/J8707 and J8742B, and between J8742A
and P/J8723.
The wiring is good.
YN
Repair the open or short circuit.
Measure the voltage between the finisher PWB P/J8707 pin 9 (+) and ground (-). The
voltage is approximately +5VDC.
YN
Check the +5VDC circuit. Refer to the Wiring Diagrams.
Measure the voltage between the finisher PWB P/J8707 pin 8 (+) and ground (-). Manu-
ally rotate the set clamp shaft to actuate the set clamp home sensor. The voltage
changes.
YN
Install a new set clamp home sensor, PL 12.11 Item 7.
Check the wires and connectors for an intermittent open or short circuit. If the fault per-
sists, install a new finisher PWB, PL 12.14 Item 1.
Enter dC330 code 012-017. The set clamp motor runs.
YN
Check the connections of P/J8708 and P/J8740. The connectors are good.
YN
Secure the connections.
Check for an open or short circuit between P/J8708 and P/J8740. The wiring is good.
YN
Repair the open or short circuit.
Measure the voltage between the finisher PWB P/J8708 pin 9 (+) and ground (-), and
between P/J8708 pin 11 (+) and ground (-).
Each voltage is approximately +24VDC.
YN
Check the +24VDC circuit. Refer to the Wiring Diagrams. If the fault persists, install
a new finisher PWB, PL 12.14 Item 1.
Install a new set clamp motor, PL 12.25 Item 15. If the fault persists, install a new finisher
PWB, PL 12.14 Item 1.
Check the wires and connectors for an intermittent open or short circuit. If the fault persists,
install a new finisher PWB, PL 12.14 Item 1.
