501-11-33
Glass, Frames and Mechanisms
501-11-33
SPECIFICATIONS
Lubricants, Fluids, Sealers and Adhesives
Item
Specification
Cleaner
SKM-2G9524-A
Primer
SKM-2G9525-A
1K Adhesive
WSKM-2G309-B
2K Adhesive
ESK-M2G369-A1
2K Hardener
ESK-M2G369-A2
Torque Specifications
Description
Nm
Wiper arm retaining nuts
18
Glass retaining clamp screws
5
Window regulator motor retaining nuts
8
E6784 EN
08/2001 2002 Bantam
