205-04-24 Front Drive Halfshafts 205-04-24
REMOVAL AND INSTALLATION (CONTINUED)
E6671 EN 07/2001 2002 Bantam
Installation
NOTE: Use all new circlips, self-locking nuts
and clamps.
1. Draw the front drive halfshaft stub into the
wheel hub.
• Insert the washer and screw on the front
drive halfshaft stub nut.
2.
CAUTION: The inner constant velocity
joint must not be bent at more than
18 degrees, the outer joint must not
be bent at more than 45 degrees.
NOTE: Make sure the retaining ring is securely
in place.
Install the drive halfshaft in the constant
velocity joint.
• Guide the front drive halfshaft into the
constant velocity joint until the retaining
ring clips in place.
3. Fabricate an adapter for special tool 14-
044.
• Material: aluminium or steel plate, 5 mm
thick.
