501-20B-51 Occupant Restraints — Passive — Supplemental Air 501-20B-51
Bag System
REMOVAL AND INSTALLATION (CONTINUED)
WARNING: Painting air bag module trim
covers could lead to deterioration of the
trim cover and air bag. Do not for any
reason attempt to paint discoloured or
damaged air bag module trim covers.
Install a new component. Failure to fol-
low this instruction may result in per-
sonal injury.
1. Disconnect the battery ground cable. For
additional information, refer to Section 414-
01.
2. Remove the passenger air bag module trim
cover.
3. Detach the passenger air bag module from
the instrument panel.
4. Remove the passenger air bag module.
• Disconnect the electrical connector.
08/2001 2002 Bantam
