303-01B-37 Engine — 1.6L / 1.3L RoCam 303-01B-37
IN-VEHICLE REPAIR (CONTINUED)
E6632 EN 07/2001 2002 Bantam
10. Lower the vehicle.
11. Remove the intake manifold.
Installation
1. NOTE:
Install a new gasket if the original is
damaged.
Install the intake manifold.
2. Raise and support the vehicle. For
additional information, refer to Section 100-
0
2.
3. Install the intake manifold lower retaining
bolts (shown with engine removed).
To Next Page
