303-01B-84 Engine — 1.6L / 1.3L RoCam 303-01B-84
REMOVAL (CONTINUED)
E6642 EN 07/2001 2002 Bantam
29. Disconnect the lower arm from the wheel
knuckle on both sides (left-hand side
shown).
30. Remove the inner constant velocity (CV)
joint boot clamp on both sides (right-hand
side shown).
31.
CAUTION: To prevent damage to the
halfshaft joints and boots, do not
bend the inner halfshaft joints by
more than 18 degrees, the outer one
by not more than 45 degrees.
NOTE:
Remove the grease from out of the
housing.
Remove the halfshafts on both sides (left-
hand side shown).
• Secure the halfshafts to one side.
32. NOTE: The engine roll restrictor is under
tension.
Remove the engine roll restrictor.
To Next Page
