303-01B-85 Engine — 1.6L / 1.3L RoCam 303-01B-85
REMOVAL (CONTINUED)
E6642 EN 07/2001 2002 Bantam
33. Remove the coolant return hose.
34. Position the assembly stand with wooden
blocks on it under the vehicle.
35. Carefully lower the vehicle until the engine
and transaxle assembly is on the assembly
stand.
36. Secure the engine and transaxle assembly
on the assembly stand with a retaining
strap.
37. Remove the engine rear mounting bracket.
To Next Page
