303-01D-9 Engine — 1.8L Diesel - Endura DE 303-01D-9
IN-VEHICLE REPAIR (CONTINUED)
E5881 EN 09/2001 2002 Bantam
11. Lower the engine with the engine support
bar.
12. Raise the vehicle.
1. Undo the bolt.
CAUTION: To slacken, turn the bolt
clockwise.
2. Slacken and remove the drive belt.
13. Remove the drive belt.
14. Remove the crankshaft pulley/vibration
damper.
15. Remove the lower timing belt cover.
To Next Page
