303-01D-27 Engine — 1.8L Diesel - Endura DE 303-01D-27
IN-VEHICLE REPAIR (CONTINUED)
E5882 EN 09/2001 2002 Bantam
13. CAUTION: Slacken the nuts of the
camshaft bearing caps evenly, a turn
at a time.
Remove the camshaft.
• Take out the bearing caps, bearing
shells and camshaft and put them down in
order.
• Remove the camshaft seal.
14. NOTE: Put down the valve tappets in order.
Remove the valve tappets and the valve
shims and check them for wear.
15. Release the valve spring retainers by
tapping lightly on the ends of the valve
stems.
16. Turn the crankshaft to bring the pistons of
cylinders nos. 1 and 4 to TDC.
• Mark the position.
