303-01D-37 Engine — 1.8L Diesel - Endura DE 303-01D-37
IN-VEHICLE REPAIR (CONTINUED)
E6447 EN 09/2001 2002 Bantam
13. Remove the crankshaft belt pulley/vibration
damper.
14. Remove the lower timing belt cover.
15. Remove the belt tensioner.
16. Remove the generator and lay it to one
side.
